E-Lektron C-192A Mini DMX controller 12x 16 Total 192 Channels
192-CHANNEL DMX CONTROL PANEL
E-Lektron C-192A
Compact, portable 192-channel DMX controller for use in lighting systems with up to 12 DMX-controlled lights. The controller can control 12 light effects via up to 16 DMX channels each. The controller has 8 sliders for this purpose, the channels are divided into 2 pages.
The device is suitable for stages, mobile entertainers, DJ's, etc.
Properties:
- Lighting control desk with 12x 16 effect channels
- Blackout button
- Speed and fade controls
- 23 banks with 8 programmable scenes each (184 scenes in total)
- 6 programmable chase sequences with up to 240 steps each
- Processes can be activated individually or one after the other
- Automatic sequence with adjustable fade and step time (0.1 - 10 min)
- Manual sequence of steps at the push of a button
- Music beat control of the steps via integrated microphone
- Protocol: DMX-512 (USITT), occupies channels 1-192
- Connection via XLR sockets
- Power supply: 12Vdc / 0.5A via included power supply
- Dimensions: 29 (W) x 16 (D) x 2.5 (H) cm
- Weight: approx 1.1kg
- Scope of delivery: C-192A DMX controller, power supply unit, operating instructions
