Citronic CAB 12" inch Active Powerful 1200W Speaker with Bluetooth Stereo Link
Active 12" Speaker With BT Link - CAB Series
The Citronic CAB 12L Active Speaker is a powerful and efficient PA speaker with BT wireless connectivity and stereo link capability. The lightweight and compact injection moulded polypropylene enclosure houses custom-designed low and high-frequency drivers powered by a digital amplifier circuit, delivering energy-efficient performance.
The speaker features a switchable Mic/Line input, a separate Line input, and a Bluetooth receiver for playback from smartphones or tablets. The BT section also allows wireless connection to another CAB series speaker for stereo pairing. The speaker also includes integral top and side carry handles, 2 inputs with separate volume control, a 35mm pole mount, and flying point anchors built-in.
With a power supply of 240Vac, 50Hz (IEC), the speaker offers a frequency response of 53Hz - 19kHz and has a maximum SPL of 134dB. The main driver is a 300mmØ (12") woofer with a 50mmØ (2") voice coil and a crossover frequency of 2.8kHz. The speaker measures 603 x 355 x 350mm and weighs 14.2kg.
Note that the Bluetooth receiver with stereo link capability can only be paired with two of the same model speaker, either 2 of 178.012UK or 2 of 178.015UK. The speaker also features Power on, Limit, and Bluetooth link LEDs, as well as a Line output in XLR format.
Features：
- Bluetooth receiver with stereo link capability
- Digital amplifier for lightweight & efficient performance
- Integral top and side carry handles
- 2 inputs with separate volume control
- 35mm pole mount
- Flying point anchors built in.
Technical Specifications：
- Power supply: 240Vac, 50Hz (IEC)
- Housing material: Injection moulded polypropylene
- Amplifier construction: Class D + Class AB
- HF driver: 35mmØ (1.35") Ti compression driver
- Dispersion: 90° x 60°
- Inputs: Mic/Line XLR or jack, Line XLR or RCA, Bluetooth
- Indicators: Power on, Limit & Bluetooth link LEDs
- Line output: XLR
- Frequency response: 53Hz - 19kHz
- Output power RMS: 300W
- Output power peak: 1200W
- Max. SPL: 134dB
- Main driver: 300mmØ(12") woofer
- Voice coil: 50mmØ (2")
- Crossover frequency: 2.8kHz
- Dimensions: 603 x 355 x 350mm
- Weight: 14.2kg
